Overview
Yansen YSS600E-X-XXX is a well-balanced 2.5 SATA SSD with standard form factor and great performance. Designed in SATA 6 Gb/s interface, the SSD is able to deliver exceptional read/write speed, making it the ideal companion for heavy-loading industrial or server operations.
YSS600E-X-XXX utilizes 2D NAND and max capacity up to 1TB, external DRAM design makes the drive has great performance for 4KB files, the drive comes with various implementations including powerful hardware ECC engine, power saving modes, wear leveling, flash block management, S.M.A.R.T. and TRIM.
Features
Interface：SATA3.0(6Gb/s)
Low-Density Parity-Check (LDPC) Code
Global Wear Leveling
Flash bad-block management
Flash Translation Layer: Page Mapping
Support S.M.A.R.T.
Support TRIM
Power Loose Protection PLP
Specifications
| Product Model | YSS600E-X-XXX |
| Flash Type | MLC |
| Capacity | 128GB~2TB |
| Sequential Read（MAX） | Up to 560MB/s |
| Sequential Write（MAX） | Up to 480MB/s |
| 4K Random Read | 65090 IOPS |
| 4K Random Write | 65200 IOPS |
| Operating Temperature | -20°C ~ 70°C, -40°C ~ 85°C |
| Storage Temperature | -55°C ~ +95°C |
| Humidity | 5%-95% RH non-condensing |
| Shock | 1500G/0.5ms |
| Vibration | 80Hz~2000Hz/20G |
| Operating Voltage | DC 5V±5% |
| Power Consumption（MAX） | 4.2W |
| Dimensions | L100.4mm*W70mm*H7.0mm ±0.15mm |
| MTBF | 2 million hours |
Order Information
| Temperature | 128GB | 256GB | 512GB | 1TB |
-20°C ~ 75°C | YSS600E-M-128 (Enhance Series) | YSS600E-M-256 (Enhance Series) | YSS600E-M-512 (Enhance Series) | YSS600E-M-1T (Enhance Series) |
-40°C ~ 85°C | YSS600E-M-128 （Extreme Series） | YSS600E-M-256 （Extreme Series） | YSS600E-M-512 （Extreme Series） | YSS600E-M-1T （Extreme Series） |
Application
Aerospace
Embedded
Server
Surveillance
